| Model | | | | EVO BLACK |
| GTT model | | | | |
| USB port | | | | 3 |
| The panel material of the chassis | | | | Glass +ABS fog surface |
| Structure size W/O panel (WxDxH) | | |
| 445*290*415mm |
| Product size with front panel (WxDxH) | | |
| 445*290*415mm |
| Metal (SECC/SGCC/SPCC)/Thickness | | | | 0.8mm |
| Form factors | | | | ATX/M-ATX/ITX |
| 5.25" Expose | | | | 0 |
| 3.5" Expose | | | | 0 |
| 3.5" Hidden | | | | 2 |
| 2.5" Hidden | | | | 2 |
| Front I/O | USB3.0*1+USB2.0*2+HD AUDIO |
| Slots | | | | 7 |
| Tool-less | | | | Y |
| Front (fan option) | |
| | 0 |
| Rear (fan option) | |
| | 1*12 |
| Side (fan option) | |
| | 3*12 |
| Top (fan option) | |
| | 3*12 |
| Bottom (fan option) | |
| | 3*12 |
| Mesh filer at bottom/top | | | | Y |
| PSU | | | | PS2 |
| Security lock | |
| | NA |
| Maximum length of graphics | | |
| 422mm |
| Maximum height of CPU | | |
| 168mm |
| Front/rear/top a few centimeters water-cooled fan | | | | 120-360mm |
| Cu'ft/CTN | | | | 1pcs/CTN |
| Packing Size (WxDxH) | | | | 483*385*546mm |
| N.W. / G.W. (kg) | |
| | 10kg/13kg |
| 20ft | | | | |
| 40ft | | | | |
| 40ft HQ | | | | 670 |
