| Model | | | | NV2302 |
| USB port | | | | 3 |
| Quality of the side panels of the chassis | | | | Tempered glass side panel + metal side panel |
| Structure size W/O panel (WxDxH) | | | | 340*215*410mm |
| Product size with front panel (WxDxH) | | | | 370*215*410mm |
| Metal (SECC/SGCC/SPCC)/Thickness | | | | 0.45-0.5mm Blacken by roasting |
| Form factors | | | | M-ATX/ITX |
| 5.25" Expose | | | | 0 |
| 3.5" Expose | | | | 0 |
| 3.5" Hidden | | | | 2 |
| 2.5" Hidden | | | | 2 |
| Front I/O | USB3.0*1+USB*2+HD AUDIO |
| Slots | | | | 5 |
| Tool-less | | | | Y |
| Front (fan option) | | | | 3*12cm/2*14cm |
| Rear (fan option) | | | | 1*12cm |
| Side (fan option) | | | | 0 |
| Top (fan option) | | | | 2*12cm/2*14cm |
| Bottom (fan option) | | | | 0 |
| Mesh filer at bottom/top | | | | Top + bottom |
| PSU | | | | PS2 |
| Security lock | | | | NA |
| Maximum length of graphics | | | | 320mm |
| Maximum height of CPU | | | | 165mm |
| Front/rear/top a few centimeters water-cooled fan | | | | Front360mm/rear120mm/top240mm/top280mm |
| Cu'ft/CTN | | | | 1pcs/CTN |
| Packing Size (WxDxH) | | | | 460*265*455mm |
| N.W. / G.W. (kg) | | | | 4.6kg/5.5kg |
| 20ft | | | | |
| 40ft | | | | |
| 40ft HQ | | | | 1210 |
